Description
• Pure sine wave output
• Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc).
• Built-in MPPT solar charge controller
• MAX PV Array Open Circuit Voltage: 400V
• Combining solar system, AC utility, and battery power source to supply continuous power
• Overload, short circuit and Deep discharge protection
• Cold start function
• Support USB, RS485, CAN monitoring function
• WIFI remote monitoring (Built in wifi module and antenna)
• PV/ AC activation function
• BMS communication function
| MODEL | PV18-3524 PREM |
|---|---|
| Nominal Battery System Voltage | 24VDC |
| INVERTER OUTPUT | |
| Rated Power | 3500VA / 3500W |
| Surge Power | 7000W |
| Waveform | Pure sine wave |
| AC Voltage Regulation (Batt.Mode) | 230VAC±5%(Setting) |
| Inverter Efficiency(Peak) | 90% |
| Transfer Time | 10ms (UPS / VDE4105) / 20ms (APL) |
| AC INPUT | |
| Voltage | 230VAC±5% |
| Selectable Voltage Range | 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VED4105) |
| Frequency Range | 50Hz / 60Hz(Auto sensing) |
| BATTERY | |
| Normal voltage | 24VDC |
| Floating Charge Voltage | 27.4VDC |
| Overcharge Protection | 30VDC |
| SOLAR CHARGER & AC CHARGER | |
| Maximum PV Array Open Circuit Voltage | 400VDC |
| Maximum PV input voltage | 18A |
| Charging Algorithm | 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li) |
| Maximum PV Array Power | 4000W |
| PV Array MPPT Voltage Range | 60~320 VDC |
| Maximum Solar Charge Current | 100A |
| Maximum AC Charge Current | 60A |
| Maximum Charge Current | 100A |
| MECHANICAL SPECIFICATIONS | |
| Machine Dimension (W*H*D) | 367.5*120.9*318mm |
| Package Dimension (W*H*D) | 459.410*200mm |
| G.W | 6.7kg |
| N.W | 7.7kg |
| OTHER | |
| Humidity | 5% to 95% Relative humidity (Non-condensing) |
| Operating Temperature | 0°C~50°C |
| Storage Temperature | -15℃ ~60℃ |
