Description
Key Features
-
Ultra-Slim Wall-Mounted Design: Save valuable floor space. The all-in-one chassis is incredibly compact and supports both wall-mounted and floor-standing setups, allowing for a clean and professional residential installation.
-
High-Performance Pure Sine Wave Power: Choose between a 3.5KW or 5.5KW inverter to deliver clean, stable 230V AC power. It safely runs sensitive electronics, refrigerators, and heavy-duty household appliances without risking damage.
-
A-Grade LiFePO4 Battery: Available in 3072Wh and 5120Wh capacities. Built with premium, A-grade Lithium Iron Phosphate cells, it provides exceptional safety, thermal stability, and a staggering 6000+ deep cycles (@ 80% DOD, 25°C).
-
Massive Solar Harvesting: Maximize your green energy. The built-in advanced MPPT controller supports huge solar arrays—up to 4000W for the 3.5KW model and up to 6000W for the 5.5KW model—ensuring rapid off-grid energy replenishment.
-
Seamless 10ms UPS Backup: In the event of a grid failure, the system acts as an Uninterruptible Power Supply (UPS), switching to battery power in a lightning-fast 10ms to keep essential desktop computers, routers, and home security systems online.
-
Smart Color Display & WiFi: Features an easy-to-read, vibrant color display for real-time monitoring of power status. Built-in WiFi and an intelligent BMS allow for comprehensive remote monitoring and safe operation directly from your smartphone.
Applications
-
Whole-Room Home Backup: Keep your refrigerator running, lights on, and communication devices charged during severe weather and unexpected grid blackouts.
-
Off-Grid Cabins & Tiny Homes: A powerful, self-contained energy hub that seamlessly integrates with rooftop solar panels to provide independent, reliable electricity for remote living.
-
Smart Solar Self-Consumption: Store excess solar power generated during the day in the high-capacity battery, and discharge it during peak evening hours to drastically reduce electricity bills.
Core Specifications Table
| Model | HBP19-3524 VPM | HBP19-5548 VPM |
| System Design | All-in-One ESS (Wall/Floor Mount) | All-in-One ESS (Wall/Floor Mount) |
| Rated AC Output Power | 3500 W (3.5 KW) | 5500 W (5.5 KW) |
| Output Waveform | Pure Sine Wave | Pure Sine Wave |
| Battery Energy (Capacity) | 3072 Wh | 5120 Wh |
| Nominal System Voltage | 24V DC | 48V DC |
| Battery Specification | 25.6V 120Ah (A-Grade LiFePO4) | 51.2V 100Ah (A-Grade LiFePO4) |
| AC Output Voltage | 230V AC ±5% | 230V AC ±5% |
| AC Input Voltage Range | 90 ~ 280VAC (APL) / 170 ~ 280VAC (UPS) | 90 ~ 280VAC (APL) / 170 ~ 280VAC (UPS) |
| Max Solar Power Input | 4000 W | 6000 W |
| PV MPPT Voltage Range | 30 ~ 320V DC | 60 ~ 360V DC |
| Max PV Input Current | 18A | 28A |
| Max AC Charge Current | 60A | 100A |
| UPS Transfer Time | Typical 10ms (20ms max) | Typical 10ms (20ms max) |
| Cycle Life | 6000+ Cycles (@ 80% DOD, 25°C) | 6000+ Cycles (@ 80% DOD, 25°C) |
| Communication Interface | USB / WIFI | USB / WIFI |
| Dimensions (W*H*D) mm | 486 * 640 * 160 | 486 * 850 * 160 |
| Net Weight (kg) | 41 kg | 58 kg |
| Warranty | Inverter: 2 Years / Battery: 5 Years | Inverter: 2 Years / Battery: 5 Years |
