Description
■ CPU controlled
■ Auto re-starts when AC recovers
■ Silence setup
■ Automatic charging(offline charging)
■ Battery low voltage protection
■ Overload short circuit protection
■ Wide input voltage range
■ AVR function
■ Cold start function
■ Generator compatible
| MODEL | EW2110-600 | EW2110-1200 | EW2110-2000 |
| RatedPower | 650VA/390W | 1200VA/720W | 2000VA/1200W |
| INPUT | |||
| Input Voltage | 110V/120 VAC or 220/230/240 VAC | ||
| Input Voltage range | 85-145VAC/145-290VAC | 85-145VAC/175-275VAC | |
| Input Frequency | 45~65 Hz | ||
| OUTPUT | |||
| AC Output Port | 2 | 3 | 2 |
| Output Voltage | 110/120 VAC or 220/230/240 VAC | ||
| Output Voltage range | 102-132VAC/200-255VAC | 102-132VAC/200-240VAC | |
| Output frequency | 60±0.5 Hz or 50±0.5 Hz (Auto sensing) | ||
| Output Wave form | PWM (Batt. mode) | ||
| Transfer time | Typical 2-6ms,10ms max | ||
| BATTERY | |||
| QTY. & capacity of battery | 12V/7ah*1pcs | 12V/7ah*2pcs | 12V/9ah*2pcs |
| Charge time | 4-6 hours recover to 90% capacity | ||
| PROTECTION | |||
| Full protection | Low voltage & overload & short circuit protection | ||
| PHYSICAL | |||
| Machine Dimension(W*H*D)(mm) | 284*95*140 | 345*146*162 | 345*122*192 |
| N.W(kg) | 3.9 | 7 | 11 |
| G.W(kg) | / | / | / |
| Standard Warranty | 1years | ||
| ENVIRONMENT | |||
| Environment of performance | Temperature 0°C~ 40°C, Humidity 20%~90% | ||
| Noise level | Less than 40dB | ||
| MANAGEMENT | |||
| LCD or LED, RJ45/11 & USB (optional) | |||
| Remark: EW series indicate LED UPS, EW-C series indicate LCD UPS. | |||
