Description
Key Features
-
Long Cycle Life (≥6000): Engineered with premium LiFePO4 cells to provide 6000+ deep discharge cycles (at 25°C), ensuring over a decade of reliable service life compared to just 2-3 years for lead-acid.
-
Smart BMS Protection: Integrated Battery Management System (BMS) monitors voltage, current, and temperature in real-time, protecting against over-charge, over-discharge, short-circuit, and thermal runaway.
-
High Discharge Power: Most models support a Maximum Continuous Discharge Current of 100A, capable of powering 1200W-2500W inverters and heavy loads seamlessly.
-
IP54 Rugged Design: The high-strength ABS+PC enclosure is rated IP54, offering excellent resistance to dust and water splashes, making it suitable for semi-outdoor or marine environments.
-
Scalable Energy: Supports Series and Parallel connections, allowing users to expand voltage (up to 48V typically) or capacity to meet larger energy storage needs.
-
Bluetooth Monitoring (Optional): Can be equipped with Bluetooth connectivity, enabling users to check battery status, SOC, and health via a smartphone App.
-
Lightweight & Efficient: Delivers high energy density in a compact form factor, weighing significantly less than equivalent lead-acid batteries, perfect for weight-sensitive applications like RVs.
Applications
-
RV & Camper Vans: Lightweight and long-lasting power for life on the road.
-
Solar Energy Storage: Efficiently stores solar energy for off-grid cabins and home backup.
-
Marine & Trolling Motors: Durable IP54 design withstands marine environments.
-
Lead-Acid Replacement: Drop-in upgrade for golf carts, mobility scooters, and UPS systems.
Core Specifications Table
(Models grouped by Voltage. Values separated by “/” indicate different capacity options.)
| Model | LP15-1250 / 12100 | LP15-12200 / 12300 | LP15-24100 | LP15-24200 / 24300 |
| Nominal Voltage | 12.8V | 12.8V | 25.6V | 25.6V |
| Nominal Capacity | 50Ah / 100Ah | 200Ah / 300Ah | 100Ah | 200Ah / 300Ah |
| Nominal Energy | 640Wh / 1280Wh | 2560Wh / 3840Wh | 2560Wh | 5120Wh / 7680Wh |
| Max Cont. Discharge | 50A / 100A | 100A / 100A | 100A | 100A |
| Rec. Charge Current | 20A / 40A | 40A / 60A | 20A | 40A / 60A |
| BMS Cut-Off (Discharge) | 10.8V | 10.8V | 21.6V | 21.6V |
| Dimensions (mm) | 260*167*210 / 339*185*218 | 502*186*243 / 384*204*272 | 502*186*243 | 522*240*218 / 635*244*200 |
| Net Weight (kg) | 5.6 / 12 | 21 / 27 | 20 | 37 / 47 |
| Protection Class | IP54 | IP54 | IP54 | IP54 |
(Note: Cycle life is rated at ≥6000 cycles @ 25°C. Dimensions vary significantly by capacity, please check installation space.)
