High cycle life
6000 Cycles (25℃, 80% DOD) for effectively lower total of ownership cost.
Longer service life
Low maintenance batteries with stable chemistry.
Built in circuit protection
Battery Management System (BMS) is incorporated against abuse.
up to 6 months thanks to its extremely low self discharge (LSD) rate and no risk of sulphation.
Save time and increase productivity with less down time thanks to superior charge/discharge efficiency.
Extreme heat tolerance
Suitable for use in a wider range of applications where ambient temperature is unusually high: up to +60°C.
Lithium batteries provide more Wh/Kg while also being up to 1/3 the weight of its SLA equivalent.
|Life Cycles||6000 Cycles (25℃, 80% DOD)|
|Recommended Charge Voltage||14.6V|
|Recommended Charge Current||20A|
|End Of Discharge Voltage||10V|
|Maximum Continuous Current||Charge||25A||50A||100A|
|BMS Cut-Off Voltage||Charge||15.4 V (3.85V/Cell)|
|Discharge||9.2 V (2s) (2.3V/Cell)|
|Temperature||Charge||-4 ~ 113 ℉ (0 ~ 45℃ )|
|Discharge||-4 ~ 131 ℉ (-20 ~ 55 ℃ )|
|Storage Temperature||23~95 ℉ (-5~35℃ )|
|Dimension (L x W x H)||260x167x210mm 10.3 x 6.6 x 8.3”||339x185x218mm 13.4 x 7.3 x 8.6”||502x186x243mm 19.8 x 7.3 x 9.6”|
|Approx. Weight||16.53 lbs (7.5 kg)||26.5 lbs (12 kg)||50.7 lbs (23 kg)|
|Charge retention and capacity recovery capability||Standard charge the battery, and then put aside at room temperature for 28d or 55 ℃ for 7d, Charge retention rate≥90%, Recovery rate of charge≥90|
