LP1600 Series (25.6V-50/100/200Ah)

LiFePO4 Battery 1280Wh/2560Wh/5120Wh

MUST wall mounted Lithium battery solutions are highly integrated, deep cycle backup power solutions for your solar home energy storage system. With rich experience and advanced techniques, the product has the features of the fashionable design, high energy, high power density, long service life, and easiness of installation and expansion.

Model Certification & Standards
LP16-25100, LP16-25200 CE-EMC(EN 61000-6-3: 2007+A1: 2011+AC: 2012 EN IEC 61000-6-1: 2019)
LP16-256100, LP16-24100 IEC62619-1:2018
LP16-256200, LP16-24200 IEC62619-1:2018
LP16-25650, LP16-256100, LP16-256200 RoHS-2011/65/EU and 2015/863/EU
Description

Description

FEATURES:

High cycle life

6000 Cycles (25℃, 80% DOD) for effectively lower total of ownership cost.

Longer service life

Low maintenance batteries with stable chemistry.

Built in circuit protection

Battery Management System (BMS) is incorporated against abuse.

Better storage

Up to 6 months thanks to its extremely low self discharge (LSD) rate and no risk of sulphation.

Quickly recharge

Save time and increase productivity with less down time thanks to superior charge/discharge efficiency.

Extreme heat tolerance

Suitable for use in a wider range of applications where ambient temperature is unusually high: up to +60°C.

Lightweight

Lithium batteries provide more Wh/Kg while also being up to 1/3 the weight of its SLA equivalent.

Specification:

MODEL LP16-2450 LP16-24100 LP16-24200
Nominal Voltage 25.6V
Nominal Capacity 50Ah 100Ah 200Ah
Nominal energy 1280Wh 2560Wh 5120Wh
Life Cycles 6000 Cycles (25℃, 80% DOD)
Recommended Charge Voltage 29.2V
Recommended Charge Current 10A 20A 40A
End Of Discharge Voltage 22V
Standard Method Charge 10A 20A 40A
Discharge 25A 50A 100A
Maximum Continuous Current Charge 50A 100A 100A
Discharge 50A 100A 100A
BMS Cut-Off Voltage Charge 29.2 V (3.65V/Cell)
Discharge 22.0V (2s) (2.75V/Cell)
Temperature Charge -4 ~ 113 ℉ (0 ~ 45℃ )
Discharge -4 ~ 131 ℉ (-20 ~ 55 ℃ )
Storage Temperature 23~95 ℉ (-5~35℃ )
Shipment voltage ≥25.6V
Module Parallel Up to 15 units
Communication CAN2.0/RS232/RS485
Case Material SPPC
Dimension (L x W x H) 340 x 400 x 140

mm

13.4x 19.3 x 8.3”

450 x 400 x 140

mm

27.5 x 19.3 x 8.3””

450 x 395 x224

mm

227.5 x 19.2 x 8.8”

Approx. Weight 30.4lbs (13.8kg) 50.71lbs (23kg) 99lbs (45kg)
Charge Retention And Capacity Recovery Capability Standard charge the battery, and then put aside at room temperature for 28d or 55 ℃ for 7d, Charge retention rate≥90%, Recovery rate of charge≥90
