Description
Key Features
-
Pure Sine Wave Output: Provides clean, utility-grade power (THD < 3%), ensuring 100% compatibility with sensitive electronics like laptops, medical CPAP machines, and power tool chargers.
-
Widespread USB Charging: Unlike many competitors, this series retains a convenient 5V/1A USB Output Port on nearly all models (300W, 600W, 1000W, 1500W, and 2000W 12V/24V versions), making it easy to charge phones without occupying the AC socket. (Note: USB is not available on the PI15-2048 48V model).
-
Smart Digital Display (600W+): Models from 600W upwards feature a built-in LED Digital Screen that cycles through critical data: Battery Voltage, Output Power, Output Voltage, and Error Codes for instant status awareness.
-
2x Peak Surge Power: Robust internal components deliver a starting surge of up to 2 times the rated power (e.g., 4000W surge for the 2000W model), capable of starting inductive loads like small motors and fridges.
-
Comprehensive Protection: Built-in safeguards against Low Voltage, Over Voltage, Reverse Polarity, Short Circuit, and Over Temperature, protecting both your battery and your appliances.
-
Lithium Battery Friendly: Optimized voltage protection thresholds ensure compatibility with both Lead-Acid and Lithium (LiFePO4) battery banks.
Applications
-
Road Trips & Camping: Charge phones via USB while powering a mini-fridge or fan via AC.
-
Trucking (24V): The 1000W/1500W 24V models are perfect for truck cabs to run microwaves and entertainment systems.
-
Mobile Office: Pure sine wave ensures interference-free operation for sensitive laptops and audio equipment.
Core Specifications Table
(Models grouped by power rating. Values separated by “/” indicate parameters for different voltage versions.)
| Model | PI15-0312 / 0324 | PI15-0612 / 0624 | PI15-1012 / 1024 | PI15-1512 / 1524 | PI15-2012 / 2024 / 2048 |
| Rated Power | 300W | 600W | 1000W | 1500W | 2000W |
| Peak Power (Surge) | 600W | 1200W | 2000W | 3000W | 4000W |
| DC Input Voltage | 12V / 24V | 12V / 24V | 12V / 24V | 12V / 24V | 12V / 24V / 48V |
| AC Output Voltage | 230VAC | 230VAC | 230VAC | 230VAC | 230VAC |
| USB Output | Yes (5V/1A) | Yes (5V/1A) | Yes (5V/1A) | Yes (5V/1A) | Yes (Except 2048) |
| Display Type | LED Status | LED Digital | LED Digital | LED Digital | LED Digital |
| Dimensions (mm) | 205*125*61 | 242*158*81 | 291*220*83 | 381*248*90 | 381*248*90 |
| Net Weight | 1.0 kg | 1.7 kg | 2.6 kg | 4.5 kg | 4.5 kg |
(Note: The PI15-2048 (48V Model) is the only unit where the USB port is NC/Not Connected.)
