Description
Features:
• Pure sine wave output
• 3 Steps charging
• MFD (multi-function display)
• Overload and short-circuit protection
• Set charging voltage/charging current.
• Battery low voltage shutdown point can be set to 10/10.5/11/11.5V
• Power-save mode
• Set utility priority/ Battery priority
• Set utility input wide/narrow range
• Inverter voltage can be set to 110V/115V/120V
• Inverter frequency can be set to 50/60Hz
• Set utility charging on/off switch
• Acid or Lithium Select
• WiFi port (optional)
Specification:
MODEL | EP30-4KW LV2 | EP30-5KW LV2 | EP30-6KW LV2 | |
---|---|---|---|---|
Nominal Battery System Voltage | 24VDC | 48VDC | 48VDC | 48VDC |
INVERTER OUTPUT | ||||
Reted Power | 4KW | 5KW | 6KW | |
Surge Rating | 12000VA | 15000VA | 18000VA | |
Capable Of Starting Electric Motor | 2HP | 3HP | ||
Waveform | Pure sine wave/ same as input (bypass mode) | |||
Nominal Output Voltage RMS | 110V/115V/120VAC ±10% (RMS) | |||
Output Frequency | 50Hz / 60Hz±0.3 Hz | |||
Inverter Efficiency(Peak) | >88% | |||
Line Mode Efficiency | >95% | |||
Power Factor | 1.0 | |||
Typical Transfer Time | 10ms(max) | |||
AC INPUT | ||||
Voltage | 120VAC | |||
Selectable Voltage Range | 80~135VAC(For Personal Computers) | |||
Frequency Range | 50Hz/60Hz (Auto sensing) 40~80Hz | |||
BATTERY | ||||
Minimum Start Voltage | (10V / 10.5V / 11V / 11.5V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
Low Battery Alarm | (10V / 10.5V / 11V / 11.5V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
Low Battery Cut off | 10V / 10.5V / 11V / 11.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
High Voltage Alarm | (13.8-14.5V)+1V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
High Battery Voltage Recover | (13.8-14.5V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
Idle Consumption-Search Mode | Load ≤50±20W(120V) | |||
CHARGER | ||||
Output Voltage | Depends on battery type | |||
Charger AC Input Breaker Rating | 4-6KW/63A | |||
Overcharge Protection S.D. | 15.7VDC for 12VDC mode (*2 for 24VDC mode, *4 for 48VDC mode) | |||
Maximum Charge Current | 60A | 30A | 35A | 40A |
BYPASS & PROTECTION | ||||
Input Voltage Waveform | Sine wave (grid or generator) | |||
Nominal Input Frequency | 50Hz or 60Hz | |||
Overload Protection (SMPS Load) | Circuit breaker | |||
Output Short Circuit Protection | Circuit breaker | |||
AC Input Breaker | 50A / 63A | |||
MECHANICAL SPECIFICATIONS | ||||
Mounting | Wall Mount | |||
Dimensions (W*H*D) (mm) | 305.4*531*200.3 | |||
Net Weight (Solar CHG) (kg) | 38.2 | 35.8 | 45 | |
Shipping Dimensions(W*H*D) (mm) | 400*319*686 | |||
Shipping Weight (Solar CHG) (kg) | 42.3 | 40 | 49.3 | |
OTHER | ||||
Operation Temperature Range | 0°C to 40°C | |||
Storage Temperature | -15°C to 60°C | |||
Audible Noise | 60dB MAX | |||
Display | LED+LCD |
