Description
■ Pure sine wave output
■ 3 steps charging
■ Overlord and short- circuit protection
■ Set charging voltage/charging current
■ Power-save mode
■ Battery low voltage shutdown point can be set to 10/10.5/11/11.5/12V
■ Inverter voltage can be set to 100/110/120V
■ Inverter frequency can be set to 50/60Hz
■ Acid or Lithium select
■ WIFI monitoring function (optional)
■ With BMS lithium battery communication function (CAN port)
| MODEL | EP33-4024 TLV | EP33-4048 TLV | EP33-5048 TLV | EP33-6048 TLV |
| INVERTER OUTPUT | ||||
| Rated power | 4KW | 5KW | 6KW | |
| Surge rating | 12000VA | 15000VA | 18000VA | |
| Capable of starting electric motor | 2P | 3P | ||
| Power factor | 1 | |||
| Wave form | Pure sine wave / Same as input wave form (bypass mode) | |||
| Output voltage RMS | 100V / 110V / 120VAC (200V / 220V / 240VAC) ±10% | |||
| Output frequency | 50Hz or 60Hz (±0.3Hz) (can be set) | |||
| Overload protection | Breaker + software protection | |||
| Output short circuit | Breaker + software protection | |||
| Inverter efficiency (peak) | >85% | |||
| Overload | 100% < Load < 110% (alarm 5min then stop output and fault code 07) 110% < Load < 125% (alarm 60s then stop output and fault code 07) Load > 125% (alarm 10s then stop output and fault code 07) | |||
| BATTERY | ||||
| Battery voltage | 24VDC / 48VDC | 48VDC | ||
| Minimum start voltage | (10V/ 10.5V/ 11V/ 11.5V/ 12V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
| Low battery voltage cut off | 10V/ 10.5V/ 11V/ 11.5V/ 12V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
| Low battery voltage alarm | (10V/ 10.5V/ 11V/ 11.5V/ 12V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
| High battery voltage alarm | (12-14.5V)+1V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
| High Battery Voltage Recover | (12-14.5V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
| Save mode | Load ≤50±20W(120V)/100±20W(220V) | |||
| AC INPUT MODE | ||||
| Input waveform | Pure sine wave | |||
| Nominal input voltage | 200Vac / 220Vac / 240Vac | |||
| Max input voltage | 270Vac MAX | |||
| Input frequency | 50Hz / 60Hz (auto sensing) | |||
| Efficiency (AC mode) | >95% (load, full battery) | |||
| Transfer time AC to DC | 15ms(max) | |||
| Transfer time DC to AC | 15ms(max) | |||
| CHARGE MODE | ||||
| Boost voltage | 14.1V(Default) Range of adjustment 12-14.5V / *2 for 24VDC / *4 for 48VDC (Regulation step 0.1V) | |||
| Float voltage | 13.5V(Default) Range of adjustment 12-14.5V / *2 for 24VDC / *4 for 48VDC (Regulation step 0.1V) | |||
| 12V | / | / | / | |
| 24V | 60A | / | / | |
| 48V | 30A | 35A | 40A | |
| Min charge current 10A. Change by every 5A | ||||
| DIMENSIONS | ||||
| Machine Dimension (W*H*D) | 361.8*543.5*188.5mm | |||
| Package Dimension (W*H*D) | 698*407*308mm | |||
| Warranty | 1 year | |||
| CERTIFICATION & STANDARDS | ||||
| CE-EMC+LVD (EN6100-6-3, EN6100-6-1+EN IEC62109-1, EN IEC62109-2) | ||||
