Description
Inverter Module
Low frequency solar single phase inverter can output the direct current(DC) from the rooftop solar PV array into alternating current(AC), so your home or business loading can use it directly.
Battery Module
The MUST HBP3300 TLV Series is with a ground-breaking LiFePO4 battery pack, that offers multiple energy storage options through, which further simplifies installation and O&M with multiple smart functions.
Specification:
| MODEL | HBP30-2024 TLV | HBP30-3024 TLV | HBP30-5048 TLV | HBP30-6048 TLV |
|---|---|---|---|---|
| Inverter | ||||
| Rated power | 2000W | 3000W | 5000W | 6000W |
| Output voltage waveform | Pure sine wave | |||
| Output voltage regulation | 100V / 110V / 120VAC (200V/220V/ 240VAC, L+L) ±10% | |||
| Output frequency | 50Hz or 60Hz (±0.2Hz) | |||
| Peak efficiency | 85% | |||
| Nominal DC input voltage | 24Vdc | 48Vdc | ||
| Standby Consumption | < 2W | |||
| PV Input | ||||
| Max solar power input | 2500W | 5000W | ||
| PV max charging current | 80A | |||
| Combined charging current | 80A | |||
| Max efficiency | 98% max | |||
| PV array open circuit voltage | 145VDC | |||
| PV Array MPPT Voltage Range | 30~130VDC | 64~130VDC | ||
| AC Input | ||||
| AC input voltage | 200/220/240VAC | |||
| Acceptable input voltage range | 155~280VAC | |||
| Nominal input frequency | 50Hz / 60Hz (Auto detection) | |||
| Transfer time | 10ms(max) | |||
| AC Charge | ||||
| Charging current @ Nominal input voltage | 30A | 40A | 35A | 40A |
| Charging Algorithm | 4-step (Li) | |||
| Output | ||||
| AC output | Terminal & Socket (10A max) | |||
| Lithium Battery | ||||
| Energy | 6400wh | 12800wh | ||
| Nominal voltage | 25.6V | 51.2V | ||
| Battery capacity | 250Ah | |||
| Standard charging and discharge current | 100A | |||
| Maximum continuous charging & discharge current | 100A | |||
| Operation ambient temperature | -10~50℃ | |||
| Storage ambient temperature | -20~55℃ | |||
| Dimension | ||||
| Net Weight | 73Kg | 75Kg | / | / |
| Gross Weight | 88Kg | 90Kg | / | / |
