Description
Key Features
-
Plug-and-Play Modular Stacking: Eliminate complex cables and brackets. The LP3000 features an innovative wireless interlocking design between modules, allowing for rapid deployment and effortless capacity upgrades.
-
Massive Scalability: A single stack supports up to 8 modules (40.96kWh). For commercial needs, connect up to 60 units in parallel to achieve a staggering total capacity of 307.2kWh.
-
High Power Output (10KW): Delivers a continuous power output of 10KW (for 2+ modules) and a peak surge of 12KW for 30 seconds, easily starting heavy loads like 5-ton air conditioners, heat pumps, and EV chargers.
-
IP65 Indoor & Outdoor Ready: The fully sealed metal enclosure is IP65 waterproof and dustproof, allowing for versatile installation in garages, basements, or outdoors (under a shade/canopy).
-
Ultra-Long 8000+ Cycle Life: Utilizes premium Cobalt-Free Lithium Iron Phosphate (LiFePO4) chemistry, delivering over 8000 deep cycles and backed by a comprehensive 10-Year Warranty for absolute peace of mind.
-
Smart Independent BMS: Each module contains an intelligent Battery Management System with built-in WiFi and BLE. Monitor cell voltage, SOC, and temperature in real-time, and execute remote firmware updates via the smartphone app.
-
Wide Inverter Compatibility: Pre-programmed to communicate flawlessly (via CAN/RS485) with over 15 of the world’s most popular hybrid inverter brands.
Applications
-
Premium Home Backup: A 10kWh-20kWh stack provides complete energy independence for large homes during blackouts.
-
Outdoor Installations: Perfect for homes with limited indoor space, safe to install on patios or under eaves (IP65).
-
Small Commercial & Light Industrial: Scale up to 300+ kWh to shave peak demand charges for businesses and workshops.
Core Specifications Table
(Models are configured by stacking the LP30-48100 5.12kWh base module. All operate at 51.2V Nominal Voltage.)
| Configuration | LP30-5.1 | LP30-10.2 | LP30-15.3 | LP30-20.4 | LP30-30.6 | LP30-40.8 |
| Number of Modules | 1 Module | 2 Modules | 3 Modules | 4 Modules | 6 Modules | 8 Modules |
| Energy Capacity | 5.12 kWh | 10.24 kWh | 15.36 kWh | 20.48 kWh | 30.72 kWh | 40.96 kWh |
| Usable Capacity | 4.91 kWh | 9.83 kWh | 14.75 kWh | 19.66 kWh | 29.49 kWh | 39.32 kWh |
| Max Output Power | 5 KW | 10 KW | 10 KW | 10 KW | 10 KW | 10 KW |
| Max Charge Current | 50 A | 75 A | 100 A | 125 A | 175 A | 200 A |
| Max Disch. Current | 100 A | 200 A | 200 A | 200 A | 200 A | 200 A |
| Dimensions (mm) | 620*360*360 | 620*360*570 | 620*360*780 | 620*360*1090 | 620*360*1410 | 620*360*1830 |
| Weight (kg) | 62 | 112 | 162 | 212 | 312 | 412 |
| Protection Rating | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 |
