Description
Key Features
-
Detachable Remote Control LCD: Features a magnetic, removable LCD panel that serves as a remote control. It can be wired up to 40 meters away from the inverter, perfect for hidden installations where physical access to the unit is difficult.
-
Enhanced Connectivity (Bluetooth + WiFi): In addition to WiFi, this series integrates Bluetooth for quick, short-range local setup and monitoring via mobile app, ensuring connection stability even without internet access.
-
High-Power PV Input (10KW Model): The 10KW model is optimized for high-yield systems, featuring Dual MPPT with a massive 13,000W (6500W x 2) PV input capacity to maximize solar utilization.
-
Battery-Independent Operation: Capable of powering loads directly from PV panels or the grid without a battery connected, offering a lower entry cost for users who want to add storage later.
-
Smart Dual AC Outputs: Intelligent load management automatically prioritizes critical appliances on the main output while managing secondary loads based on battery capacity.
-
Parallel Scalability: Supports parallel connection of up to 6 units (Single or Three Phase), making it adaptable for growing power requirements.
Applications
-
Remote/Hidden Installation: Ideal for homes where the inverter is installed in a garage, attic, or utility room, but the user wants to monitor status from the hallway or living room.
-
Flexible Energy Systems: Perfect for users who need a robust system now (PV+Grid) but plan to invest in battery storage in the future (Battery-Free mode).
-
High-Solar Yield Homes: The 10KW model’s high PV input limit is excellent for properties with large roof space maximizing green energy generation.
Core Specifications Table
| Model | PH19-6048 EXP II | PH19-10048 EXP II |
| Rated Power | 6000W | 10000W |
| Battery Voltage | 48VDC | 48VDC |
| Surge Power | 12000W | 20000W |
| Max PV Voltage | 500VDC | 500VDC |
| MPPT Trackers | 2 | 2 |
| Max PV Input Power | 7800W | 13000W (6500W x 2) |
| MPPT Voltage Range | 90~430VDC | 90~430VDC |
| Max PV Current | 18A x 2 | 27A x 2 |
| Max Solar Charge | 120A | 150A |
| Max AC Charge | 100A | 150A |
| Dimensions (mm) | 309*505*147 | 425*527*145 |
| Net Weight | 12.9 kg | 18.1 kg |
| Key Differentiator | Detachable LCD / Bluetooth | Detachable LCD / Bluetooth |
