Description
Key Features
-
Split Phase Output Flexibility: Delivers versatile power options with 100V/110V/120V for standard household appliances and 200V/220V/240V for heavier loads, all from a single unit.
-
Robust Low Frequency Design: Built with a large transformer, it offers superior isolation and stability, capable of withstanding high inrush currents from motors (up to 3HP) and ensuring long-term durability.
-
High-Efficiency MPPT Charging: Includes a built-in 80A MPPT solar charger with a wide operating voltage range, maximizing energy extraction from solar panels up to 5000W (on 48V models).
-
Advanced Battery Management: Fully compatible with Lead-Acid and Lithium batteries, featuring BMS communication (CAN port) and customizable charging parameters including low-voltage cutoff settings.
-
Smart & Customizable: Offers a wide range of user-programmable settings via LCD, such as Utility/Battery priority, charging current, and output voltage/frequency (50Hz/60Hz), adapting to various application needs.
-
Complete Protection: Comprehensive safety features include overload, short-circuit, over-temperature, and deep discharge protection.
Applications
-
Home Backup Power: Ideal for homes in 110V/220V split-phase regions needing reliable backup for essential appliances and pumps.
-
Remote Cabins & RVs: Perfect for off-grid living where a mix of 120V and 240V appliances are used.
-
Sensitive Electronics: The pure sine wave output and transformer isolation provide clean power for sensitive audio/video equipment and computers.
Core Specifications Table
| Model | PV33-3024 TLV | PV33-3048 TLV | PV33-4024 TLV | PV33-4048 TLV | PV33-5048 TLV | PV33-6048 TLV |
| Rated Power | 3000W | 3000W | 4000W | 4000W | 5000W | 6000W |
| Battery Voltage | 24VDC | 48VDC | 24VDC | 48VDC | 48VDC | 48VDC |
| Output Voltage | 110V/220V Split Phase | 110V/220V Split Phase | 110V/220V Split Phase | 110V/220V Split Phase | 110V/220V Split Phase | 110V/220V Split Phase |
| Surge Power | 9000VA | 9000VA | 12000VA | 12000VA | 15000VA | 18000VA |
| Motor Capability | 1.5HP | 1.5HP | 2HP | 2HP | 3HP | 3HP |
| Max PV Voltage | 245VDC | 245VDC | 245VDC | 245VDC | 245VDC | 245VDC |
| MPPT Range | 30~230VDC | 60~230VDC | 30~230VDC | 60~230VDC | 60~230VDC | 60~230VDC |
| Max PV Power | 2500W | 5000W | 2500W | 5000W | 5000W | 5000W |
| Max Solar Charge | 80A | 80A | 80A | 80A | 80A | 80A |
| Max AC Charge | 40A | 20A | 60A | 30A | 35A | 40A |
| Dimensions (mm) | 359*443*188 | 359*443*188 | 362*544*188 | 362*544*188 | 362*544*188 | 362*544*188 |
