Description
Available in power ratings from 1.5 kW to 6 kW with storage capacities of 7.68 kWh (24V architecture) and 15.36 kWh (48V architecture), the system features a modular stackable design that separates the inverter and battery units for easy transport and rapid two-person installation. With flexible dual AC outputs (terminal block plus a dedicated 10A socket), computer-grade 10ms transfer time, integrated generator auto-start compatibility, and comprehensive BMS safety monitoring, the HBP3000 provides a resilient, plug-and-play energy security foundation.
Key Features
-
Modular Stackable Design & Easy Handling:
-
Vertical two-box stackable architecture neatly separates the inverter host from the heavy battery module.
-
Facilitates effortless two-person handling, fast on-site assembly, simplified maintenance, and a minimal floor footprint.
-
-
High-Capacity & Long-Lasting LiFePO4 Battery:
-
Utilizes premium 300Ah lithium iron phosphate (LiFePO4) chemistry known for superior thermal stability and extended cycle life.
-
Delivers 7,680 Wh (24V models) or 15,360 Wh (48V models) of usable storage, supporting up to 200A maximum continuous charge and discharge current.
-
-
Integrated 80A MPPT Solar Charge Controller:
-
Built-in 80A MPPT controller achieves up to 98% conversion efficiency to extract peak solar energy throughout the day.
-
High PV open-circuit voltage rating up to 245Vdc with wide MPPT tracking windows (30–230Vdc for 24V models; 60–230Vdc for 48V models), supporting up to 2,500W / 5,000W PV arrays.
-
-
Flexible Dual AC Output for Smart Load Management:
-
Equipped with dual output options: hardwired terminal blocks for home wiring and a convenient direct socket (10A max).
-
Enables smart load distribution between whole-house circuits and essential plug-in appliances, improving overall power utilization.
-
-
UPS-Grade 10ms Seamless Transfer & Generator Auto-Start:
-
Ultra-fast line-to-battery transfer time (≤ 10ms) guarantees uninterrupted operation for desktop computers, networking gear, and sensitive home electronics during blackouts.
-
Supports generator connection with an integrated auto-start dry contact interface, establishing automated multi-source power redundancy.
-
-
Smart BMS Protection & Ultra-Low Idle Consumption:
-
Intelligent Battery Management System (BMS) continuously monitors cell voltage, temperature, and operating currents in real time.
-
Features ultra-low standby power consumption (< 2W), full CE-EMC compliance, a 2-year inverter warranty, and a 5-year lithium battery warranty.
-
Technical Specifications
| Category | Parameter | HBP30-1524 | HBP30-2024 | HBP30-3024 | HBP30-5048 | HBP30-6048 |
| Inverter AC Output | Rated Output Power | 1,500 W | 2,000 W | 3,000 W | 5,000 W | 6,000 W |
| Output Voltage Waveform | Pure Sine Wave | Pure Sine Wave | Pure Sine Wave | Pure Sine Wave | Pure Sine Wave | |
| Output Voltage Regulation | 220V / 230V / 240Vac ± 10% | 220V / 230V / 240Vac ± 10% | 220V / 230V / 240Vac ± 10% | 220V / 230V / 240Vac ± 10% | 220V / 230V / 240Vac ± 10% | |
| Output Frequency | 50 Hz / 60 Hz (±0.2 Hz) | 50 Hz / 60 Hz (±0.2 Hz) | 50 Hz / 60 Hz (±0.2 Hz) | 50 Hz / 60 Hz (±0.2 Hz) | 50 Hz / 60 Hz (±0.2 Hz) | |
| Peak Inverter Efficiency | 88% | 88% | 88% | 88% | 88% | |
| Nominal DC Input Voltage | 24 Vdc | 24 Vdc | 24 Vdc | 48 Vdc | 48 Vdc | |
| Standby Self-Consumption | < 2 W | < 2 W | < 2 W | < 2 W | < 2 W | |
| AC Output Interface | Terminal & Socket (10A max) | Terminal & Socket (10A max) | Terminal & Socket (10A max) | Terminal & Socket (10A max) | Terminal & Socket (10A max) | |
| Solar PV Input (MPPT) | Max. Solar Power Input | 2,500 W | 2,500 W | 2,500 W | 5,000 W | 5,000 W |
| PV Max. Charging Current | 80 A | 80 A | 80 A | 80 A | 80 A | |
| Combined Charging Current | 80 A | 80 A | 80 A | 80 A | 80 A | |
| Max. MPPT Efficiency | 98% Max. | 98% Max. | 98% Max. | 98% Max. | 98% Max. | |
| PV Array Open Circuit Voltage (Voc) | 245 Vdc | 245 Vdc | 245 Vdc | 245 Vdc | 245 Vdc | |
| PV Array MPPT Voltage Range | 30 – 230 Vdc | 30 – 230 Vdc | 30 – 230 Vdc | 60 – 230 Vdc | 60 – 230 Vdc | |
| AC Input & Utility Charger | Nominal AC Input Voltage | 230 Vac ± 5% | 230 Vac ± 5% | 230 Vac ± 5% | 230 Vac ± 5% | 230 Vac ± 5% |
| Acceptable Voltage Range | 150 – 265 Vac (Personal Computers) | 150 – 265 Vac | 150 – 265 Vac | 150 – 265 Vac | 150 – 265 Vac | |
| Nominal Input Frequency | 50 Hz / 60 Hz (Auto Detection) | 50 Hz / 60 Hz | 50 Hz / 60 Hz | 50 Hz / 60 Hz | 50 Hz / 60 Hz | |
| Transfer Time | ≤ 10 ms (Max.) | ≤ 10 ms (Max.) | ≤ 10 ms (Max.) | ≤ 10 ms (Max.) | ≤ 10 ms (Max.) | |
| AC Charging Current | 25 A | 30 A | 35 A | 40 A | 40 A | |
| Charging Algorithm | 4-step (Lithium) | 4-step (Lithium) | 4-step (Lithium) | 4-step (Lithium) | 4-step (Lithium) | |
| Lithium Battery Module | Total Battery Energy | 7,680 Wh (7.68 kWh) | 7,680 Wh (7.68 kWh) | 7,680 Wh (7.68 kWh) | 15,360 Wh (15.36 kWh) | 15,360 Wh (15.36 kWh) |
| Nominal Battery Voltage | 25.6 Vdc | 25.6 Vdc | 25.6 Vdc | 51.2 Vdc | 51.2 Vdc | |
| Battery Rated Capacity | 300 Ah | 300 Ah | 300 Ah | 300 Ah | 300 Ah | |
| Standard Charge / Discharge Current | 100 A / 150 A | 100 A / 150 A | 100 A / 150 A | 100 A / 150 A | 100 A / 150 A | |
| Max. Continuous Current | 200 A | 200 A | 200 A | 200 A | 200 A | |
| Operating Temperature | Charging: 0°C to 50°C | Discharging: -20°C to 55°C | |||||
| Dimensions & Packaging | Machine Dimensions (W×H×D) (Inverter + Battery) | 600 × 617 × 470 mm | 600 × 617 × 470 mm | 600 × 617 × 470 mm | 600 × 754 × 470 mm | 600 × 754 × 470 mm |
| Inverter Package Dimensions (W×H×D) | 707 × 315 × 575 mm | 707 × 315 × 575 mm | 707 × 315 × 575 mm | 707 × 315 × 575 mm | 707 × 315 × 575 mm | |
| Battery Package Dimensions (W×H×D) | 700 × 590 × 585 mm | 700 × 590 × 585 mm | 700 × 590 × 585 mm | 700 × 710 × 590 mm | 700 × 710 × 590 mm | |
| Warranty & Certifications | Standard Warranty | Inverter: 2 Years | Lithium Battery: 5 Years | Inverter: 2 Years | Lithium Battery: 5 Years | Inverter: 2 Years | Lithium Battery: 5 Years | Inverter: 2 Years | Lithium Battery: 5 Years | Inverter: 2 Years | Lithium Battery: 5 Years |
| Certification Standards | CE-EMC | CE-EMC | CE-EMC | CE-EMC | CE-EMC |
