Description
- 280Ah Prismatic Cell Architecture: Massive 7.16kWh or 14.33kWh storage capacity ensures multi-day energy autonomy.
- Pure Sine Wave Power: 1.5KW to 6KW continuous output with high peak surge handling for inductive loads.
- Dual AC Output Distribution: Smart dual output terminals enable load prioritization and optimized branch circuit distribution.
- Integrated 80A MPPT Solar Charger: Maximizes solar energy conversion with up to 5000W PV input.
- Generator Auto-Start Interface: Dedicated dry contact connection for automated backup generator synchronization.
| Parameter | HBP30-1524 | HBP30-2024 | HBP30-3024 | HBP30-5048 | HBP30-6048 |
| Nominal Battery System Voltage | 24VDC | 24VDC | 24VDC | 48VDC | 48VDC |
| Inverter Rated Power | 1500W | 2000W | 3000W | 5000W | 6000W |
| Output Waveform & Voltage | Pure Sine Wave, 220V/230V/240VAC ±10%, 50/60Hz (±0.2Hz) | ||||
| Max PV Array Power / VOC | 2500W / 245VDC (MPPT: 30-230VDC) | 2500W / 245VDC | 2500W / 245VDC | 5000W / 245VDC (MPPT: 60-230VDC) | 5000W / 245VDC |
| Max PV / Combined Charge Current | PV: 80A; Max Combined: 80A | 80A | 80A | 80A | 80A |
| AC Charge Current @ Nominal Volt | 25A | 30A | 40A | 35A | 40A |
| Battery Capacity & Energy | 25.6V 280Ah (7168Wh) | 25.6V 280Ah (7168Wh) | 25.6V 280Ah (7168Wh) | 51.2V 280Ah (14336Wh) | 51.2V 280Ah (14336Wh) |
| Max Cont. Charge/Discharge | 100A / 100A | 100A / 100A | 100A / 100A | 100A / 100A | 100A / 100A |
| Machine Dimensions (WHD) | 600 x 617 x 470 mm (24V Series) | 600 x 617 x 470 mm | 600 x 617 x 470 mm | 600 x 754 x 470 mm (48V Series) | 600 x 754 x 470 mm |
| Certifications & Warranty | Inverter: 2 Years; Battery: 5 Years; CE-EMC, ISO |
