Description
- Ultra-High Voltage Operating Platform: Connects up to 23 modules in series per cluster, achieving an 883.2V system configuration.
- High-Capacity 200Ah Modules: Larger modular blocks reduce total system interconnect layout and simplify power path routing.
- 220A Heavy Industrial Breaker: Outfitted with an integrated heavy-duty internal circuit breaker to provide reliable protection against large load fluctuations.
- High Peak Surge Capacity: Supports large continuous current handling, with an exceptional 200A peak discharge capacity for up to 10 seconds.
- Durable & Long-Lasting Lifecycle: Industrial formulation delivers over 8000 deep discharge cycles with premium thermal tolerance under high loads.
| Parameter | Specification |
| Base Module Specification | HP2900 PRO (51.2V / 200Ah / 7.68kWh modular architecture) |
| System Model Lineup | HV29P-46.1 up to HV29P-176.6 (6 to 23 Modules per cluster) |
| Nominal Energy Portfolio | Single Cluster options spanning 46,080Wh up to 176,640Wh |
| Nominal Voltage Profile | 230.4V DC up to 883.2V DC |
| Max System Output Power | 35kW up to 130kW max per cluster |
| Max Charge / Discharge Current | 150A continuous |
| Chassis Mechanical Core | SPCC Structural Steel Cases / IP20 Protection |
| Standard Warranty | 10 Years |
