PH1800 LV Series (AC120V: 3/6KW)

High Frequency On/Off Hybrid Solar Inverter

PH1800 LV Series is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.

Description

Description

• Pure sine wave solar inverter

• Output power factor 1

• Built-in 80A MPPT solar charger

• 2 units can be wired in parallel to create a split-phase system with 120V and 240V capabilities for 3KW)

• Support parallel operation up to 3 units (3K Parallel in single phase)

• WIFI remote monitoring (optional)

• CAN/RS485 communication for BMS

• Compatible to generator

MODEL PH18-3024 LV PH18-3048 LV
Nominal Battery System Voltage 24VDC 48VDC
INVERTER OUTPUT
Rated Power 3000W 3000W
Surge Power 6000W 6000W
Waveform Pure sine wave
AC Voltage Regulation (Batt.Mode) 120VAC ±5% 120VAC ±5%
Inverter Efficiency(Peak) 90%
Transfer Time 10ms (UPS / UL) 20ms (APL)
AC INPUT
Voltage 120VAC 120VAC
Selectable Voltage Range 107~132VAC(UL)
Frequency Range 50Hz / 60Hz(Auto sensing)
BATTERY
Normal voltage 24VDC 48VDC
Floating Charge Voltage 27.4VDC 54.8VDC
Overcharge Protection 30VDC 60VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage 250VDC 250VDC
Maximum Solar Charge Current 100A 80A
PV Array MPPT Voltage Range 90-200VDC 60-200VDC
PV Input Power 4000W 4000W
Maximum Efficiency 98%
Maximum AC Charge Current 80A 60A
Maximum Charge Current 100A 140A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D) 329*485*134mm 329*485*134mm
Package Dimension (W*H*D) 425*575*229mm 425*575*229mm
G.W 12kg 12kg
N.W 13.5kg 13.5kg
OTHER
Humidity 5% to 95% Relative humidity (Non-condensing)
Operating Temperature -10°C~50°C
Storage Temperature -15℃ ~60℃
