Description
■ Portable and easy carry
■ Multiple Charging Ways Available: AC Charging, Solar Charging
■ HD Screen: the power status is clear at a glance
■ Multiple outputs can supply power for various electrical appliances.
■ Intuitive battery endurance indicate
| Model | HBP15-0612 | HBP15-1012 | HBP15-1224 |
| Nominal Battery System Voltage | 12VDC | 24VDC | |
| INVERTER OUTPUT | |||
| Rated Power | 600VA / 600W | 1000VA / 1000W | 1200VA / 1200W |
| Waveform | Pure Sine Wave | ||
| Nominal Output Voltage RMS | 230V | ||
| Output Voltage Regulation | +10/-18% | ||
| Output Frequency | 50Hz / 60Hz ±1Hz | ||
| Inverter Efficiency (Peak) | >90% | ||
| Line Mode Efficiency | >95% | ||
| Typical Transfer Time | Typical < 10ms , 20ms max | ||
| AC INPUT | |||
| Voltage Nominal | 230VAC | ||
| Voltage Range | 176 ~ 278VAC ± 3% | ||
| Frequency Range | 45 ~ 65Hz ± 2Hz | ||
| Frequency Nominal | 50Hz / 60Hz (Auto Detection) | ||
| SOLAR CHARGER & AC CHARGER | |||
| Maximum AC Charge Current | 20A | 15A | |
| Maximum PV Charge Current | 40A (max) | ||
| Maximum Charge Current AC+PV | 40A (max) | ||
| Maximum PV Array Power | 600W | 1200W | |
| MPPT Operating Voltage Range | 15 ~ 75VDC | 30 ~ 75VDC | |
| Maximum PV Array Open Voltage | 105VDC | ||
| Maximum Efficiency | > 95% | ||
| DC OUTPUT | |||
| USB Type A | 5V 2.1A * 4ch | ||
| USB Type C | 5V 1A * 1ch | ||
| DC output | 9V 1A + 12V 1A | ||
| PROTECTION | |||
| Battery Input Protection | FUSE | ||
| Load Output Protection | FUSE | ||
| Bypass Fuse Rating | 6.3A | 10A | 10A |
| LITHIUM BATTERY | |||
| Battery Energy | 538Wh/ 640Wh | 1280Wh | 1076Wh/ 1280Wh |
| Nominal Input Voltage | 12.8VDC (4 Series LiFePO4) | 25.6VDC (8 Series LiFePO4) | |
| Low Battery Cutoff | 11.5VDC | 23.0VDC | |
| Low Battery Alarm | 12.0VDC | 24.0VDC | |
| Low Battery Voltage Recover | 12.8VDC | 25.6VDC | |
| High Battery Voltage Recover | 14.5VDC | 29.0VDC | |
| High Battery Voltage Cutoff | 15.0VDC | 30.0VDC | |
| MECHANICAL SPECIFICATIONS | |||
| Machine Dimension (W*H*D)(mm) | 225* 304*335 | ||
| Package Dimension (W*H*D)(mm) | 307* 375 *417 | ||
| N.W(kg) | 12 | 17 | 17 |
| G.W(kg) | 14 | 19 | 19 |
| OTHER | |||
| Operation Temperature Range | 0°C ~ 45°C | ||
| Display | LED+LCD | ||
| CERTIFICATION & STANDARDS | |||
| CE-EMC | |||
