Description
- Safe Low-Voltage Battery Chemistry: High-capacity 300Ah LiFePO4 cells configured in 1S (3.2V) or 2S (6.4V) for exceptional safety and cell balancing.
- High Peak Efficiency: Over 87% inverter efficiency in battery mode and over 95% in line mode.
- Versatile Multi-Source Charging: Supports solar PV panels, XT60 high-current inputs, car DC sockets, and AC adapters.
- Clear Visual LED Indicators: Intuitive LED display for real-time tracking of operating states, battery levels, and faults.
| Parameter | HBP18-0503 | HBP18-1006 |
| Nominal Battery System Voltage | 3.2VDC (1S LiFePO4) | 6.4VDC (2S LiFePO4) |
| Rated Inverter Power | 500VA / 500W | 1000VA / 1000W |
| Output Waveform & Voltage | Pure Sine Wave, 230VAC (170-235VAC), 50/60Hz ±1Hz | Pure Sine Wave, 230VAC (170-235VAC), 50/60Hz ±1Hz |
| Max PV Array Power | 300W | 550W |
| MPPT Operating Voltage / Max VOC | 11-55VDC / 55VDC | 11-55VDC / 55VDC |
| Max PV / AC Charge Current | PV: 77A; AC: 135A | PV: 75A; AC: 140A |
| Max Combined Charge Current | 140A | 140A |
| Battery Capacity & Energy | 300Ah (960Wh) | 300Ah (1920Wh) |
| Transfer Time | <=20ms | <=20ms |
| Dimensions (WHD) | 297 x 233 x 254 mm | 297 x 255 x 308 mm |
| Gross Weight | 14 kg | 21 kg |
| Certifications | CE, ISO | CE, ISO |
