Description
- Clean Pure Sine Wave Output: 600W to 1200W continuous output ensures optimal protection for sensitive electronic devices.
- High-Efficiency MPPT Solar Controller: Integrated 40A MPPT controller supporting up to 1200W solar array for rapid energy replenishment.
- Versatile Multi-Port Matrix: 4 USB-A ports (5V/2.1A), 1 USB-C port, DC 12V, DC 9V, and standard 230V AC outlets.
- Safe and Stable LiFePO4 Battery: Built-in 640Wh or 1280Wh LiFePO4 battery pack with intelligent multi-stage charging algorithms.
- Smart LCD Display: High-definition display offers clear visibility of battery percentage, power flow, and system alerts.
| Parameter | HBP15-0612 | HBP15-1012 | HBP15-1224 |
| Nominal Battery System Voltage | 12VDC | 12VDC | 24VDC |
| Rated Inverter Power | 600VA / 600W | 1000VA / 1000W | 1200VA / 1200W |
| Output Waveform & Voltage | Pure Sine Wave, 230VAC (+10/-18%), 50/60Hz ±1Hz | Pure Sine Wave, 230VAC (+10/-18%), 50/60Hz ±1Hz | Pure Sine Wave, 230VAC (+10/-18%), 50/60Hz ±1Hz |
| Max PV Array Power | 600W | 600W | 1200W |
| MPPT Voltage Range | 15-75VDC (VOC: 105VDC) | 15-75VDC (VOC: 105VDC) | 30-75VDC (VOC: 105VDC) |
| Max PV / Combined Charge Current | 40A / 40A Max | 40A / 40A Max | 40A / 40A Max |
| Max AC Charge Current | 20A | 20A | 15A |
| AC Input Voltage Range | 176-278VAC ±3%, 50/60Hz | 176-278VAC ±3%, 50/60Hz | 176-278VAC ±3%, 50/60Hz |
| Battery Energy | 640Wh (12.8VDC LiFePO4) | 1280Wh (12.8VDC LiFePO4) | 1280Wh (25.6VDC LiFePO4) |
| DC Outputs | 4x USB-A (5V 2.1A), 1x Type-C, DC 9V 1A, DC 12V 1A | 4x USB-A (5V 2.1A), 1x Type-C, DC 9V 1A, DC 12V 1A | 4x USB-A (5V 2.1A), 1x Type-C, DC 9V 1A, DC 12V 1A |
| Transfer Time | Typical <10ms (20ms max) | Typical <10ms (20ms max) | Typical <10ms (20ms max) |
| Dimensions (WHD) | 225 x 304 x 335 mm | 225 x 304 x 335 mm | 225 x 304 x 335 mm |
| Net Weight | 12 kg | 17 kg | 17 kg |
| Certifications | CE-EMC, ISO | CE-EMC, ISO | CE-EMC, ISO |
