Description
- Ultra-Portable Dual-Handle Design: Ergonomic dual-handle housing ensures effortless mobility and rugged outdoor durability.
- Flexible Multi-Port Output: Simultaneous power delivery via 2 AC sockets, USB-C PD 60W/18W, USB-A QC 18W, and DC5521 ports.
- 24/7 Seamless Power Switching: Fast transfer time (under 15ms) guarantees uninterrupted power supply without complicated setup.
- Three Versatile Charging Methods: Supports solar charging (up to 600W), AC grid charging, and 12V/24V car charging for all energy scenarios.
- Smart Visual Monitoring: High-definition display provides real-time operating metrics, load level, and battery status.
- Safe and Long-Lasting LiFePO4 Chemistry: Industrial-grade LiFePO4 battery core with multi-level BMS protection against overcharge, deep discharge, and short circuits.
| Parameter | EM1024S |
| Nominal Battery System Voltage | 24VDC |
| Inverter Rated Power / Peak Power | 1000W / 2000W (Max) |
| Output Waveform | Pure Sine Wave |
| Output Voltage & Frequency | 230VAC ±5%, 50Hz/60Hz (±0.2Hz) |
| Max Solar Power Input | 600W |
| PV Array MPPT Voltage Range | 12-60VDC (Max VOC: 60VDC) |
| PV Max Charging Current | 25A (Max efficiency: 95%) |
| AC Input Voltage Range | 180-260VAC, 50/60Hz |
| AC Charging Power | 600W @ 220V |
| Transfer Time | <=15ms |
| Battery Energy & Capacity | 1280Wh / 1331Wh (25.6V, 50Ah/52Ah) |
| BMS Protection Board | 100A (Charge @ 25A, Discharge @ 50A) |
| AC Output Sockets | 230VAC x 2 |
| DC Outputs | USB-C PD 60W x 2, USB-C PD 18W x 1, USB-A QC 18W x 3, DC5521 60W x 2, Car Port 120W x 1 |
| Dimensions (WHD) | 440 x 233.2 x 263.3 mm |
| Net Weight | 17.9 kg |
| Certifications & Warranty | CE-EMC, LVD, RoHS 2.0; Inverter: 2 Years, Battery: 5 Years |
