Description
- Dedicated 120VAC Output: Pure sine wave power delivery through 4 AC receptacles for standard household loads.
- 6000+ Cycles LiFePO4 Battery: 1280Wh and 2560Wh capacity options built for sustained cycling and daily backup.
- Smooth Rolling Caster Mobility: Mobile cabinet form factor allows easy positioning and relocation anywhere in the home.
- Multi-Device DC Charging: Equipped with USB Type-C, USB-A (5V), and USB-A (12V) ports for personal electronic devices.
- Comprehensive System Protections: Multi-level BMS and inverter guards against short circuits, over-temperature, and overloads.
| Parameter | HBP18-1012 LV | HBP18-2024 LV |
| Nominal Battery System Voltage | 12VDC | 24VDC |
| Inverter Rated Power | 1000W | 2000W |
| Output Waveform & AC Voltage | Pure Sine Wave, 120VAC ±5%, 50/60Hz (±0.2Hz) | Pure Sine Wave, 120VAC ±5%, 50/60Hz (±0.2Hz) |
| Max PV Array Power | 500W (VOC: 105VDC, MPPT: 15-75VDC) | 1800W (VOC: 150VDC, MPPT: 30-128VDC) |
| Max PV / Combined Charge Current | PV: 40A; Combined: 80A | PV: 60A; Combined: 100A |
| AC Input Voltage Range | 74-145VAC (UL), 50/60Hz | 107-132VAC (UL), 50/60Hz |
| AC Charge Current @ Nominal Volt | 40A | 40A |
| Battery Capacity & Energy | 12.8V 100Ah (1280Wh) | 25.6V 100Ah (2560Wh) |
| Battery Cycle Life | 6000+ Cycles @ 80% DOD, 25°C | 6000+ Cycles @ 80% DOD, 25°C |
| Machine Dimensions (WHD) | 359 x 499 x 234 mm | 420 x 497 x 280 mm |
| Net Weight | 21 kg | 30 kg |
| Certifications & Warranty | Inverter: 2 Years, Battery: 5 Years; CE-EMC, LVD (EN IEC 62109) | Inverter: 2 Years, Battery: 5 Years; CE-EMC, LVD (EN IEC 62109) |
