Description
- IP66 rugged enclosure with independent cooling air duct to prevent dust ingress and lengthen lifespan.
- 4.3-inch color touch screen with integrated WiFi and Bluetooth for intuitive operation.
- Built-in CT sensor enables real-time load monitoring and adjustable grid export power limit.
- Off-grid parallel operation supporting up to 10 units for flexible home energy expansion.
- Dual AC inputs allow seamless integration with utility grid and backup generators.
| Parameter | Specification |
| Models | PH91-3.6KL1/5KL1/6KL1/8KL1/10KL1/12KL1-EU-HM |
| Rated AC Output Power | 3600W / 5000W / 6000W / 8000W / 10000W / 12000W |
| Nominal Battery Voltage | 48V |
| Max. PV Access Power | 7200W / 10000W / 12000W / 16000W / 22000W / 26000W |
| PV Input Voltage Range | 125 – 500V |
| Max. Charge Current | 90A – 230A |
| Max. Efficiency | 97.5% |
| Enclosure Rating | IP66 |
