Description
Key Features
-
True Hybrid Functionality: Supports multiple working modes: Grid-Tie to sell excess power, Off-Grid for backup during outages, and Self-Consumption to minimize electricity bills.
-
IP66 Weatherproof & Silent: Features an IP66-rated enclosure for complete protection against water and dust. The Natural Cooling design (heatsink only, no noisy fans) ensures whisper-quiet operation, perfect for residential areas.
-
High-Efficiency Dual MPPT: Equipped with 2 Independent MPPT Trackers (on all models), allowing for flexible solar panel layout (e.g., East/West roofs) and high efficiency (99.8%).
-
Smart Battery Management: Compatible with 48V Lead-Acid and Lithium batteries. Includes specific BMS communication for lithium packs to ensure safety and longevity.
-
Robust Backup Power: Provides reliable backup power (EPS) with a switching time of <10ms, ensuring lights and internet stay on during blackouts.
-
Advanced Monitoring: Comes with built-in WiFi/GPRS capability for real-time monitoring via app, plus an intuitive LED+LCD display for local control.
Applications
-
Residential Hybrid Systems: Perfect for homeowners wanting to reduce grid reliance and have backup power without noise pollution.
-
Outdoor Installations: Can be mounted on exterior walls, garages, or exposed areas thanks to IP66 protection.
-
Energy Cost Optimization: Ideal for regions with Time-of-Use tariffs, utilizing battery storage to shift energy usage.
Core Specifications Table
| Model | PH11-3648 PRO | PH11-4048 PRO | PH11-5048 PRO | PH11-6048 PRO |
| Rated Power | 3600W | 4000W | 5000W | 6000W |
| Battery Voltage | 48VDC | 48VDC | 48VDC | 48VDC |
| Max PV Voltage | 500VDC | 500VDC | 500VDC | 500VDC |
| MPPT Voltage Range | 120~500V | 120~500V | 120~500V | 120~500V |
| MPPT Trackers | 2 | 2 | 2 | 2 |
| Max PV Input Power | 4700W | 5200W | 6500W | 7800W |
| Max Charging Current | 75A | 85A | 100A | 125A |
| Max Efficiency | 97.1% | 97.1% | 97.1% | 97.1% |
| Dimensions (mm) | 420*480*215 | 420*480*215 | 420*480*215 | 420*480*215 |
| Net Weight | 30 kg | 30 kg | 30 kg | 30 kg |
| Protection Rating | IP66 | IP66 | IP66 | IP66 |
| Cooling | Natural (Fanless) | Natural (Fanless) | Natural (Fanless) | Natural (Fanless) |
