Description
- Stable Power Output: 1.2KVA / 2.4KVA inverter output safely runs TVs, desktop computers, audio systems, and daily household electronics.
- Compact and Portable Enclosure: Lightweight, space-saving design engineered for easy carrying and fast room-to-room deployment.
- High-Capacity Long-Life Storage: Built-in 1280Wh or 2560Wh LiFePO4 battery capacity delivering 4000+ deep cycles at 80% DOD (25°C).
- Smart Monitoring and Safety Protection: Clear LCD screen displaying real-time load, voltage, and battery metrics, paired with multi-layer BMS protection.
| Parameter | HBP12-1212 | HBP12-2424 |
| Nominal Battery System Voltage | 12VDC | 24VDC |
| Rated Inverter Power | 1200VA / 720W | 2400VA / 1440W |
| Output Waveform | Modified Sine Wave | Modified Sine Wave |
| AC Voltage Regulation | 230VAC (10%-18%), 50/60Hz ±0.5Hz | 230VAC (10%-18%), 50/60Hz ±0.5Hz |
| Peak Inverter Efficiency | AC to AC: 95%, DC to AC: >80% | AC to AC: 95%, DC to AC: >80% |
| Transfer Time | Typical 15-20ms (40ms max) | Typical 15-20ms (40ms max) |
| AC Input Voltage Range | 90-280VAC (Selectable), 50/60Hz | 90-280VAC (Selectable), 50/60Hz |
| Max AC Charge Current | 20A | 20A |
| Battery Capacity & Energy | 12.8V 100Ah (1280Wh) | 25.6V 100Ah (2560Wh) |
| Battery Cycle Life | 4000+ cycles @ 80% DOD, 25°C | 4000+ cycles @ 80% DOD, 25°C |
| Machine Dimensions (WHD) | 316 x 343 x 262 mm | 436 x 383 x 282 mm |
| Net Weight | 22 kg | 35 kg |
| Certifications & Warranty | CE-EMC, RoHS, ISO; Inverter: 2 Years, Battery: 5 Years | CE-EMC, RoHS, ISO; Inverter: 2 Years, Battery: 5 Years |
